tG96 Signal Generator

Multi-standard RF Signal Generator

Highlights

9kHz ~ 6.0GHz frequency range, covering most wireless communication, radar and IoT frequency bands.
High frequency resolution : 0.23Hz, meeting high-precision demands
Analog modulation, digital modulation, pulse modulation all available
Large dynamic range. Level accuracy is less than ±1dB, high repeatability, reliable test results. Harmonic and non-harmonic suppression ≤ -40dBc / ≤ -60dBc, pure spectrum
Amplitude/frequency sweep supports step sweep and list sweep, with a maximum of 65535 points. Automatic, external, and manual trigger modes, adaptable to various test scenarios.
LAN and USB communication interfaces support remote control and data transmission.
Complete API documentations facilitate secondary development and system integration.

Specifications

Model / Items	TG96
Frequency Range	9kHz ~ 6.0GHz
Frequency Resolution	0.23Hz
Output Power Range	-120dBm ~ +10dBm
Harmonic Suppression	≤ -40 dBc
Modulation Method	AAM/FM/ΦM/Pulse/ASK/FSK/PSK
Scanning Method	Step/List Sweep
Communication Interface	LAN, USB
Operating Temperature	-10℃ ~ +45℃
Dimensions	430mm × 380mm × 100mm
Weight	≤ 3 kg

Ordering Information
Products	Order Number
Host (RF signal source)	TG96
RF upconversion option	TSG2000-RFUC
High stability time base option	SG2000-OCXO
Power Meter Control Kit	SG2000-PMC

Powerful modulation capability:

Analog modulation : AM, FM, ΦM, with modulation rate up to 1MHz.

Digital modulation : ASK/FSK/PSK, etc., supporting internal/external data sources.

Pulse modulation : Combined with linear frequency modulation, it can simulate radar signals with a rise time of only 100ns.

Built-in low-frequency signal source

Waveform types : sine, square, triangle, sawtooth.

Frequency range : 0.1Hz ~ 500kHz, can be used as an independent function generator.

Up-conversion function, strong scalability

IF input : 200MHz ±10MHz, output up to 301MHz ~ 6GHz.

Applicable scenarios : External intermediate frequency signal up-conversion, suitable for satellite communications, radar simulation, etc.

Fits for:

5G/6G communication module testing

Radar signal simulation and verification

RF performance testing of IoT devices

Education and scientific research experiments

Military and aerospace electronics testing

FAQs

What’s the test distance?

GP200 supports 40km and 100km test.

What’s the lead time?

For our standard products, if there are in stock and ready for shipment, the lead time is about 7-10 days. For our optional products, the lead time is about 25-30 days.

Do you support online training?

Yes. We understand the importance of proper operation of professional instruments.

Basic Training: We provide a detailed English operating manual.

Online Remote Training: We can provide real-time online operation training and Q&A for you and your team via video conferencing software (such as Zoom and Teams).

On-site Training: Based on project requirements, we can arrange for our engineers to conduct in-depth on-site training (travel expenses are subject to negotiation).

Training content can be customized to your specific application scenario.
